A new Uponor LoopCAD update is available for download. This is a free upgrade for all licensed users with an active subscription. Scroll down for a summary of the new features and other enhancements.

Radiant Express Upgrades

Uponor's Radiant Express design mode, also known as the Spreadsheet Mode, has several new enhanced features. If you are familiar with the previous ADS software, these new features will help you transition to the new Radiant Express. Easily complete non-drawing designs for Uponor radiant heating and snow melt systems.

View the new video tutorial to see the new advanced features in action (see Lesson #32).

View Tutorial

Advanced Circuit Editing

With the new advanced circuit editing features:

  • Adjust individual circuit lengths
  • Edit leader lengths for each circuit
  • Edit heated areas for each circuit
  • Easily edit multi-spacing settings

Whether you need to match an existing drawing details or generate an as-built design, these new features will greatly assist.

Advanced Manifold Assignment

The new advanced Manifold Assignment feature lets you edit how the circuits are assigned to the various manifolds. This can be especially helpful for larger commercial areas that require multiple manifolds. Easily control the number of manfolds and the assignment of the circuits to those manifolds.

Downward Loss Enhancements

Radiant Express allows you to manually enter the project heat loss data if you already have it available. There is new advanced feature now available that enables the automatic calculation of the downward losses, even when in this manual heat loss mode.

Upgrade Now for Free!

The Uponor Radiant Express design mode in LoopCAD 2020 is FREE for all users. Just download, install and start using it.

For the full drawing features in LoopCAD 2020 this new version of the Uponor Edition is FREE for all users with a valid subscription.

If your subscription has lapsed you can have it reinstated by following the steps below.

  1. Download, install, and run LoopCAD 2020.
  2. Click the Activate link.
  3. Click the Renew my Subscription link.
  4. Then just follow the remaining online prompts.
